Meatmeet S Pro User Manual
First Use Safety Gudies
Getting Started Guide
1. For the first time use, please use a Type-C charging cable to power the Charging Base to activate the device (exit shipping mode). You will hear a beep and the device will automatically turn on.
2. Download the free Meatmeet APP for IOS or Android.
3. Open the app, there will be an automatic pairing pop-up window when you open the device and enter the device pairing page, and use your device according to the tutorial above, or you can match your device by double clicking on the "Add device" button.
Always insert the probe past the safety line, and leave the black ceramic part at the back of the probe outside the meat. Ensure that the probe is firmly inserted into the meat before cooking.
Now, you can start enjoying cooking!
Product Information
Diagram
Button
Button Name |
Button Function |
Power button |
Press 2s for Power On/Off |
Reset button |
1) Press and hold for 3s to clear the matching record of the Booster 2) Press and hold for 5s to clear the matching record of the Booster and Reset |
LED 1
Display Status |
LED Funcion |
Slow Blink Blue |
Waiting for Bluetooth Pairing |
Solid Blue |
Pairing Successfully |
Fast Blink Blue |
Pairing Disconnected/Out of connection range |
*LED1 will turn red when Booster battery power is less than 20% |
LED 2
Display Status |
LED Funcion |
Solid Blue |
The battery is not fully charged |
Solid White |
The battery is fully charged |
Specification
Probe
Probe Model Number |
ME-TEMP02 |
Temperature Range |
Internal 32℉ - 221℉ / 0℃ - 105℃ Ambient 32℉ - 1050℉ / 0℃ - 550℃ |
Accuracy |
Internal ± 0.3℉/0.1℃ Ambient ± 9℉/5℃ |
Dimension |
5.06" x 0.19" |
Dust & Water Resistance |
IP69 |
Operating Frequency |
2402 - 2480MHz |
Charging Temperature |
0 - 45℃ |
Battery Nominal Voltage |
2.4V |
Battery Capacity |
5mAh |
Booster
Charging Base Model Number |
ME-BOX02 |
Dimension |
7.11 x 1.65 x 1.36 inches |
Operating Frequency |
2402 - 2480MHz |
Charging Temperature |
0 - 45℃ |
Dust & Water Resistance |
IPX0 |
Battery Nominal Voltage |
3.7V |
Battery Capacity |
2500mAh |
*The probe and the booster contain permanent, internal, rechargeable lithium batteries. Additional removable batteries are not required.
CAUTION
DO NOT use the Probe in a microwave or pressure cooker.
DO NOT use cleaning products containing alcohol, ammonium, benzene, abrasives, or hard cleaning tools to clean the Probe, all of which could damage the device.
DO NOT use the Probe when cooking at temperatures above 1050°F/600°C for up to 10 minutes.
DO NOT place the Charging Base directly on the grill cover, around or close to any hot surface, which will cause the Charging Base to melt or deform.
DO NOT submerge the Probe in water for a long time (over 72h), even though it is an IP69 device.
DO NOT immediatetly run the Probe in cold water after cooking.Let the probe cool down then wash.
DO NOT immediately remove the probe from the meat after cooking. Please wait for the probe to cool down or use oven gloves for operation.
The probe is SHARP! Always point the tip of the probe away from fingers, skin, or other people to avoid being scratched by the probe. Do NOT allow children to use the probe without parental supervision.
If the Probe falls into a fire or direct heat source, turn off the cooking appliance and close the lid immediately. Allow the Probe to cool completely before removing.
The Charging Base features a magnet that allows it to be attached to a refrigerator or any other iron-based object.
The Charging Base is NOT waterproof, please avoid submerging it in water or placing it in a dishwasher.
Please use a power adapter with the same nominal voltage to charge the Charging Base.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found tocomply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and uses radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
CAUTION: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.
IC Statement
This device contains licence-exempt transmitter(s)/receiver(s) that coomply with Innovation, Science and Economic Development Canada'slicence-exempt
RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may cause undesired operation of the device
IC Radiation Exposure Statement
This equipment complies with IC RSS-102 radiation exposure limits setforth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.
EU Declaration of Conformity
Hereby, the manufacturer declares that this product meets the basic requirements and applicable regulations of the Radio Equipment Directive 2014/53/EU, the EMC Directive 2014/30/EU. The complete declaration of conformity can be found at: www.meatmeet.com
Disposal of the Electronic Appliance
This electronic appliance should not be disposed of with normal household waste. Dispose of the unit at an approved facility or at your local recycling center. Please observe the current rules and regulations when disposing of the appliance. Contact your local council if in doubt.
(DE)Meatmeet S Pro User Manual
Sicherheitsanweisungen zur Erstanwendung

3. Öffnen Sie die App. Beim Einschalten des Geräts erscheint automatisch ein Popup-Fenster zur Kopplung. Befolgen Sie die Anleitung, um Ihr Gerät zu koppeln. Alternativ können Sie Ihr Gerät koppeln, indem Sie doppelt auf die Schaltfläche „Gerät hinzufügen“ klicken.


Jetzt können Sie mit dem Kochen beginnen!
Product Information
Diagram

Taste
Tastenbezeichnung
|
Tastenfunktion
|
Ein-/Aus-Taste
|
2 Sekunden drücken zum Ein-/Ausschalten
|
Reset-Taste
|
1) 3 Sekunden gedrückt halten, um den Booster-Vergleichsdatensatz zu löschen.
2) 5 Sekunden gedrückt halten, um den Booster-Vergleichsdatensatz zu löschen und zurückzusetzen.
|
LED 1
Statusanzeige
|
LED-Funktion
|
Langsam blau blinkend
|
Warten auf Bluetooth-Kopplung
|
Durchgängig blau
|
Kopplung erfolgreich
|
Schnell blau blinkend
|
Pairing Disconnected/Out of connection rangeKopplung getrennt/Außerhalb der Reichweite
|
*LED 1 leuchtet rot, wenn der Booster-Akku weniger als 20 % geladen ist.
|
LED 2
Statusanzeige
|
LED-Funktion
|
Durchgängig blau
|
Der Akku ist nicht vollständig geladen.
|
Durchgängig weiß
|
Der Akku ist vollständig geladen.
|
Spezifikationen
Sonde
Sonde Modellnummer
|
ME-TEMP02
|
Temperaturbereich
|
Intern 32℉ - 221℉ / 0℃ - 105℃
Umgebung 32℉ - 1050℉ / 0℃ - 550℃
|
Genauigkeit
|
Intern ± 0,3℉/0,1℃
|
Abmessungen
|
12,85 x 4,83 cm
|
Staub- und Wasserbeständigkeit
|
IP69
|
Betriebsfrequenz
|
2402 - 2480MHz
|
Ladetemperatur
|
0 - 45℃
|
Batterie-Nennspannung
|
2.4V
|
Kapazität der Batterie
|
5mAh
|
Booster
Modellnummer der Ladestation
|
ME-BOX02
|
Abmessungen
|
18,05 x 4,19 x 3,45 cm
|
Betriebsfrequenz
|
2402 - 2480MHz
|
Ladetemperatur
|
0 - 45℃
|
Staub- und Wasserbeständigkeit
|
IPX0
|
Batterie-Nennspannung
|
3.7V
|
Kapazität der Batterie
|
2500mAh
|
*Sonde und Booster enthalten permanente, interne, wiederaufladbare Lithiumbatterien. Zusätzliche herausnehmbare Batterien sind nicht erforderlich.
VORSICHT
EU-Konformitätserklärung
(FR)Meatmeet S Pro User Manual
Instructions de sécurité pour la première utilisation



Vous êtes maintenant prêt à cuisiner !
Informations sur le Produit
Schéma

Bouton
Désignation des Touches
|
Fonction des Touches
|
Bouton Marche/Arrêt
|
Appuyez 2 secondes pour allumer/éteindre
|
Bouton Réinitialisation
|
1) Maintenez appuyé 3 secondes pour supprimer l’ensemble de données de comparaison du booster.
2) Maintenez appuyé 5 secondes pour supprimer et réinitialiser l’ensemble de données de comparaison du booster.
|
LED 1
Indicateur de Statut
|
Fonction LED
|
Clignotement Bleu Lent
|
En Attente du Jumelage Bluetooth
|
Bleu Continu
|
Jumelage Réussi
|
Clignotement Bleu Rapide
|
Couplage déconnecté/hors de portée de connexion
|
La LED 1 s’allume en rouge lorsque la batterie du booster est chargée à moins de 20 %.
|
LED 2
Indicateur de Statut
|
Fonction LED
|
Bleu Continu
|
La Batterie N’est Pas Entièrement Chargée.
|
Blanc Continu
|
La Batterie Est Entièrement Chargée.
|
Spécifications
Sonde
Numéro de modèle de la sonde
|
ME-TEMP02
|
Plage de température
|
Interne 32℉ - 221℉ / 0℃ - 105℃
Ambiante 32℉ - 1050℉ / 0℃ - 550℃
|
Précision
|
Interne ± 0,3℉/0,1℃
|
Dimension
|
12,85 x 4,83 cm
|
Résistance à la poussière et à l'eau
|
IP69
|
Fréquence de fonctionnement
|
2402 - 2480MHz
|
Température de charge
|
0 - 45℃
|
Tension nominale de la batterie
|
2.4V
|
Capacité de la batterie
|
5mAh
|
Booster
Numéro de modèle de la base de chargement
|
ME-BOX02
|
Dimension
|
18,05 x 4,19 x 3,45 cm
|
Fréquence de fonctionnement
|
2402 - 2480MHz
|
Température de charge
|
0 - 45℃
|
Résistance à la Poussière et à l’Eau
|
IPX0
|
Tension nominale de la batterie
|
3.7V
|
Capacité de la batterie
|
2500mAh
|
ATTENTION
Déclaration UE de Conformité
(IT)Meatmeet S Pro User Manual
Guide di Sicurezza per il Primo Utilizzo


Ora potete iniziare a divertirvi cucinando!
Informazioni sul Prodotto
Schema
Gusto
Denominazione dei tasti
|
Funzione dei tasti
|
Tasto Accensione/Spegnimento
|
Premere per 2 secondi per accendere/spegnere.
|
Tasto Reset
|
1) Tenere premuto per 3 secondi per cancellare il record di confronto del booster.
2) Tenere premuto per 5 secondi per cancellare il record di confronto del booster e ripristinare.
|
LED 1
Indicatore di stato
|
Funzione LED
|
Lampeggio blu lento
|
In attesa dell’abbinamento Bluetooth
|
Blu fisso
|
Abbinamento riuscito
|
Lampeggio blu veloce
|
Abbinamento disconnesso/Fuori dal raggio di connessione
|
*Il LED 1 si illumina di rosso quando la batteria del booster è carica meno del 20%.
|
LED 2
Indicatore di stato
|
Funzione LED
|
Blu fisso
|
La batteria non è completamente carica.
|
Bianco fisso
|
La batteria è completamente carica.
|
Specifiche
Sonda
Numero modello della sonda
|
ME-TEMP02
|
Intervallo di temperatura
|
Interno: 32℉ - 221℉ / 0℃ - 105℃
Ambiente: 32℉ - 1050℉ / 0℃ - 550℃
|
Precisione
|
Interno: ± 0,3℉ / 0,1℃
|
Dimensioni
|
12,85 x 4,83 cm
|
Resistenza a polvere e acqua
|
IP69
|
Frequenza operativa
|
2402 - 2480MHz
|
Temperatura di ricarica
|
0 - 45℃
|
Tensione nominale della batteria
|
2.4V
|
Capacità della batteria
|
5mAh
|
Booster
Numero modello della stazione di ricarica
|
ME-BOX02
|
Dimensioni
|
18,05 x 4,19 x 3,45 cm
|
Frequenza operativa
|
2402 - 2480MHz
|
Temperatura di ricarica
|
0 - 45℃
|
Resistenza a polvere e acqua
|
IPX0
|
Tensione nominale della batteria
|
3.7V
|
Capacità della batteria
|
2500mAh
|
ATTENZIONE
(ES)Meatmeet S Pro User Manual
Guía de Seguridad para el Primer Uso



¡Ahora puede empezar a disfrutar cocinando!
Información del Producto
Esquema
Sabor
Denominación de los botones
|
Función de los botones
|
Botón de Encendido/Apagado
|
Mantener presionado durante 2 segundos para encender/apagar.
|
Botón de Reinicio
|
1) Mantener presionado durante 3 segundos para borrar el registro de comparación del booster.
2) Mantener presionado durante 5 segundos para borrar el registro de comparación del booster y restaurar los valores de fábrica.
|
LED 1
Indicador de estado
|
Función del LED
|
Parpadeo azul lento
|
Esperando el emparejamiento Bluetooth
|
Azul fijo
|
Emparejamiento exitoso
|
Parpadeo azul rápido
|
Emparejamiento desconectado/Fuera del alcance de conexión
|
*El LED 1 se ilumina en rojo cuando la batería del booster tiene menos del 20% de carga.
|
LED 2
Indicador de estado
|
Función del LED
|
Azul fijo
|
La batería no está completamente cargada.
|
Blanco fijo
|
La batería está completamente cargada.
|
Especificaciones
Sonda
Número de modelo de la sonda
|
ME-TEMP02
|
Rango de temperatura
|
Interior: 32℉ - 221℉ / 0℃ - 105℃
Ambiente: 32℉ - 1050℉ / 0℃ - 550℃
|
Precisión
|
Interior: ± 0,3℉ / 0,1℃
|
Dimensiones
|
12,85 x 4,83 cm
|
Resistencia al polvo y al agua
|
IP69
|
Frecuencia de operación
|
2402 - 2480MHz
|
Temperatura de carga
|
0 - 45℃
|
Voltaje nominal de la batería
|
2.4V
|
Capacidad de la batería
|
5mAh
|
Booster
Número de modelo de la estación de carga
|
ME-BOX02
|
Dimensiones
|
18,05 x 4,19 x 3,45 cm
|
Frecuencia de operación
|
2402 - 2480MHz
|
Temperatura de carga
|
0 - 45℃
|
Resistencia al polvo y al agua
|
IPX0
|
Voltaje nominal de la batería
|
3.7V
|
Capacidad de la batería
|
2500mAh
|
ADVERTENCIA
